Development of Universal Duplex Pump Control Panel for Global Market
A standardized duplex pump control panel is being developed for commercial sale, designed to operate two 3-phase pumps up to 25HP. The panel will function at 208/230V or 460V with simple conversion kits, requiring complete electrical engineering drawings and a build-ready package. The project includes detailed design specifications, a bill of materials, logic implementation, compliance with UL508A standards, and documentation for installation.

The project involves the design of a universal duplex pump control panel for two 3-phase pumps, each up to 25HP. The panel will operate at both 208/230V and 460V, utilizing conversion kits for easy adjustments.
The electrical engineer will create a comprehensive design package, including electrical schematics, a detailed bill of materials with two configurations, and logic implementation for various operational modes. The design must meet UL508A compliance and support multiple enclosure options. Deliverables include schematic packages, layout drawings, and documentation for panel construction.
