Development of Custom PCB Breadboard for DC Pump Control with ESP32
A custom PCB breadboard was designed for controlling multiple DC pumps in a liquid transfer project, featuring a dedicated SOIC-8 footprint for an AO4406 MOSFET and various protective components. The layout allows for manual connections similar to traditional breadboards, and the design was finalized and produced by NextPCB within a week. The author emphasizes the advantages of using HQDFM software for design verification and notes NextPCB's initiative to support innovative projects through free assembled RP2040-based PCBs.
Theia Market Signal Identification - AI Assisted
A custom PCB breadboard was developed for a project requiring multiple DC pumps to transfer liquid between containers. The PCB incorporates a dedicated SOIC-8 footprint for an AO4406 MOSFET, enhancing reliability compared to traditional breadboards.
It features a USB Type-C power input, an M7 diode for protection, and footprints for both SOIC-8 SMD ICs and addressable WS2812B RGB LEDs. The layout allows manual connections between unconnected pads, mimicking a traditional breadboard for ease of use.
After finalizing the design, Gerber data was submitted to NextPCB, and PCBs were received within a week, featuring a yellow solder mask and white silkscreen. The author also highlights the benefits of HQDFM software for design verification and mentions NextPCB's Accelerator campaign offering free assembled RP2040-based PCBs to support innovative projects.
