Keysight and WIN Semiconductors Launch Joint MMIC Design Workflow for RF Components
Keysight Technologies and WIN Semiconductors have introduced a new collaborative workflow for GaN MMIC design, aimed at enhancing production success rates for RF components. This solution addresses the growing demand for reliable performance validation in applications such as 5G, satellite, and defense systems.
Theia Market Signal Identification - AI Assisted
Keysight Technologies and WIN Semiconductors have developed a new design workflow for GaN MMICs, targeting improved success in initial tapeouts. This integrated solution offers multi-domain simulation, 3D routing verification, and evaluation board design within a unified environment, crucial for companies involved in RF applications.
The workflow automates simulation, optimization, and verification processes, mitigating risks associated with tapeout failures that can delay production by weeks. With the global GaN RF device market projected to reach $2.77 billion by 2031, effective performance validation through this workflow is essential for competitive differentiation. The latest GaN NP 120P process design kit from WIN Semiconductors enhances accessibility to process models, streamlining the production readiness of MMICs.
